Dyness DL5.0C 5.12kWh Lithium Battery without Heating
SKU: Dyness-DL5.0C-without heating
Dyness Stack100 S51100 Battery packs 5.12 kWh of LFP storage into a 45 kg IP65 module. Tool-free stacking, 6 000-cycle life and 95 % efficiency make this 51.2 V unit the ideal expandable battery for residential and light-commercial hybrid inverters.
- Manufacturer Dyness
The Dyness Stack100 S51100 Battery / 51.2 V 100 Ah / 5.12 kWh is a modular, low-voltage lithium-iron-phosphate (LFP) pack engineered for today’s hybrid inverters and tomorrow’s tariff-driven energy markets. Each 5.12 kWh module delivers 100 Ah at 51.2 V, providing a robust, high-density building block for residential or light-commercial storage up to 80 kWh when eight units are paralleled.
Installer-focused design
Tool-free stacking – patented slide rails and blind-mate DC/CAN connectors remove internal cabling and cut installation time by up to 40 %.
One-tech handling – at ≈ 45 kg, the module meets manual-handling guidelines; integrated carry recesses simplify movement through tight plant rooms.
Auto-address BMS – the pack automatically IDs new modules, so scaling from one to eight batteries requires no DIP switches or firmware flash.
Long-life, safe chemistry
LFP cells rated for 6 000+ cycles at 80 % DoD, delivering more than 15 years of daily cycling.
Multi-layer protection – cell-level fuses, pack BMS and solid-state cut-off provide over-charge, over-discharge, over-current and thermal safeguards.
IP65 aluminium shell keeps out dust and water spray, making the unit suitable for garages, lofts and utility cupboards.
Smart performance
Round-trip efficiency ≥ 95 % maximises self-consumption ROI.
1 C continuous / 1.5 C 10 s peak discharge supports whole-home backup and motor start loads.
Wide inverter compatibility – dual CAN & RS-485 ports integrate with Victron, GoodWe, Solis, Deye and other 48 V hybrids (see Dyness whitelist).
Optional Wi-Fi dongle streams SOC, temperature and cycle data to Dyness Cloud for fleet-level O&M.
Commercial advantages
Lower BOS costs – high capacity per module means fewer cables, breakers and racks.
Future-proof upgrades – homeowners can add extra Dyness Stack100 S51100 Battery modules as EV chargers or heat-pump loads rise.
Sustainable choice – cobalt-free LFP chemistry and recyclable aluminium casing reduce environmental footprint.
Deploy the Dyness Stack100 S51100 Battery / 51.2 V 100 Ah / 5.12 kWh to deliver durable, scalable energy storage that installs quickly, integrates seamlessly and out-performs legacy lead-acid solutions year after year.
