Sigenergy Sigen Sensor Single Phase-DH

• Manufacturer Sigenergy
• Accessory Product Type Sensors

The Sigenergy Sigen Sensor Single Phase-DH is a DIN-rail power-measurement module that gives installers 1 %-accurate import-export data without extra wiring or complex commissioning. Designed to pair instantly with SigenStor batteries and Sigen inverters, it feeds real-time values to the mySigen app every 100 ms, enabling rapid battery response, tariff optimisation and grid-code compliance.

Key benefits for installers

Plug-and-monitor integration – the sensor identifies itself on the RS485 bus; no manual setup when connected to Sigenergy devices.

High precision – built-in 100 A current transformer and 0.5 % voltage/current accuracy deliver Class 1 power readings for billing-grade control.

Fast refresh – 100 ms update interval allows sub-second battery dispatch for frequency-support or peak-shaving modes.

Compact DIN form factor – just 36 mm wide, 100 mm high; mounts on any 35 mm rail inside the consumer unit.

Wi-Fi HaLow ready – add the optional Sub1G kit to transmit data up to 200 m through walls at 868 MHz, ideal for outbuildings or thick masonry.*

Electrical & metrological specification

Grid type: 1P2W, 176–276 V AC, 50/60 Hz

Maximum operating current: 100 A direct-connected (no external CTs on the SP-DH model)

Accuracy: ±0.5 % voltage, ±0.5 % current, ±1 % power, ±0.2 % frequency

Communication: RS485, 9 600 bps, Modbus RTU protocol

Data refresh: 100 ms for instantaneous values

Mechanical & environmental

Dimensions (W × H × D): 36 × 100 × 63 mm

Weight: 0.20 kg

Ingress protection: IP20 (indoor switchboard environments)

Operating range: –25 °C to +60 °C; 0–90 % RH (non-condensing)

Storage: –40 °C to +70 °C

Compliance: EN 61010-1:2010 and EN 61010-2-030:2010 safety standards

Use-case highlights

Dynamic import/export control – precise kW data lets SigenStor hold grid export at predefined limits or follow zero-export mandates.

Tariff-aware battery scheduling – 100 ms metering synchronises charge/discharge with half-hourly price signals for maximum savings.

Fleet O&M – granular sensor data flows to Sigenergy Cloud, supporting remote diagnostics and performance guarantees.

Installation workflow

Clip the Sigenergy Sigen Sensor Single Phase-DH onto a spare DIN rail slot next to the main breaker.

Pass the live conductor through the integrated 16 mm aperture and tighten terminals.

Daisy-chain RS485 to the inverter, power up, and verify readings on the LCD and mySigen app.

For retrofit or new-build projects where space, speed and accuracy matter, the Sigenergy Sigen Sensor Single Phase-DH delivers utility-grade measurement that unlocks the full potential of smart PV-battery systems.
