Victron Phoenix Inverter 24V/1200VA/120V VE.Direct with NEMA 5-15R Socket

SKU: PIN242122500

PIN242122500

VE.Direct communication port
The VE.Direct port can be connected to:
• A computer (VE.Direct to USB interface cable needed)
• Apple and Android smartphones, tablets, MacBook’s and other devices
(VE.Direct Bluetooth Smart dongle needed)


Fully configurable:
• Low battery voltage alarm trip and reset levels
• Low battery voltage cut-off and restart levels
• Dynamic cut-off: load dependent cut-off level
• Output voltage 210 - 245V
• Frequency 50 Hz or 60 Hz
• ECO mode on/off and ECO mode sense level

Seen a better price?
Login to see Trade Prices
  • Manufacturer Victron Energy
  • Dimensions (mm) (H x W x D) 117 x 232 x 327

Monitoring:
• In- and output voltage, % load and alarms


Proven reliability
The full bridge plus toroidal transformer topology has proven its reliability over many years.
The inverters are short circuit proof and protected against overheating, whether due to overload or
high ambient temperature.


High start-up power
Needed to start loads such as power converters for LED lamps, halogen lamps or electric tools.


ECO mode
When in ECO mode, the inverter will switch to standby when the load decreases below a preset
value (min load: 15W). Once in standby the inverter will switch on for a short period (adjustable,
default: every 2,5 seconds). If the load exceeds a preset level, the inverter will remain on.


Remote on/off
A remote on/off switch can be connected to a two pole connector, or between battery plus and the
left hand contact of the two pole connector.


LED diagnosis
